A-17 UIN-36T UD Carbon fiber prepreg

UIN-36T unidirectional carbon fiber prepreg: the preferred solution for high-performance composite materials in multiple fields

In the fields of aerospace, high-end automobiles, industrial equipment, and cultural and sports supplies, the requirements for lightweight, high-strength, and scene adaptability of materials are becoming increasingly stringent. UIN-36T unidirectional carbon fiber prepreg is supported by a fiber modulus of 36GPa (36TON) as its core performance. It is not only compatible with the application scenarios of 30T unidirectional carbon fiber prepreg, but also covers multiple specifications of carbon fiber surface densities such as 25g, 30g, 75g, and 100g. It supports customization of widths ranging from 0.9 meters to 1.3 meters, and the resin system can be adjusted as needed. With its comprehensive advantages of high strength, low density, strong fatigue resistance, and excellent plasticity, it provides reliable material support for carbon fiber pipes, carbon fiber boards, and various shaped parts, while meeting the personalized needs of aerospace load-bearing structures, automotive body components, high-end cultural and sports products, and breaking the limitations of traditional materials in terms of performance and process adaptation.

Core advantages: triple guarantee of excellent performance, flexible customization, and full scene adaptation

1. 36GPa high modulus core performance, laying the foundation for the reliability of load-bearing structures

The core competitiveness of UIN-36T unidirectional carbon fiber prepreg lies in its fiber modulus of 36GPa, which enables it to achieve higher stiffness with lighter weight in load-bearing structural components, and is compatible with medium to high strength scenarios of 30T unidirectional carbon fiber prepreg, making it more widely applicable. The unidirectional fiber arrangement design (with a fiber direction consistency of 99.8%) maximizes the release of the axial mechanical properties of carbon fibers. After authoritative testing, the product's 0 ° tensile strength can reach over 2600 MPa, which is 28% higher than that of ordinary 30T unidirectional carbon fiber prepreg; The bending strength exceeds 2000MPa, and under long-term dynamic loads such as aircraft flight vibrations and high-speed car bumps, the fatigue strength retention rate still exceeds 88%, far exceeding the industry average of 80%, ensuring the stability of the core structural components in long-term service.

At the same time, the product density is strictly controlled at no less than 5% to ensure that carbon fibers are evenly distributed in the prepreg, without any weak performance points caused by local fiber sparsity. Taking the aircraft wings in the aerospace field as an example, after using UIN-36T unidirectional carbon fiber prepreg, the weight of the components is reduced by 48% compared to traditional aluminum alloys, while the stiffness is increased by 35%, directly reducing aircraft fuel consumption and takeoff load; In the application of high-pressure vessels in industrial equipment, their high-strength characteristics can reduce the wall thickness of the vessel by 28% and increase the pressure tolerance to over 45MPa, balancing safety and lightweight requirements.

2. Multi specification surface density coverage, accurately matching scene performance requirements

The product is built around a diversified specification system of carbon fiber surface density, ranging from ultra-thin 25 grams/square meter to heavy-duty 100 grams/square meter. It can be flexibly selected according to the weight and strength requirements of different components in different fields, achieving efficient adaptation through "on-demand matching":

• 25g and 30g ultra-thin specifications: featuring "ultimate lightweight", suitable for high-end cultural and sports products and precision components, such as fishing rods and golf club shafts. A fishing rod made of 25g carbon fiber prepreg weighs 18% less than ordinary carbon fiber rods, and has better toughness. It can withstand the pulling force of fish weighing over 5kg without easily breaking; The 30g specification is used for ski poles to ensure bending resistance while reducing the weight burden on athletes during swings, improving movement accuracy and explosive power.
• 75g medium specification: Balancing lightweight and structural stability, focusing on the automotive industry and rail transit fields, such as sports car door frames and subway seat brackets. The car door components made of 75g carbon fiber prepreg have a weight reduction of 42% compared to metal components and an impact resistance improvement of 25%. They can effectively cushion the impact force in collision accidents; When used as a subway seat bracket, it can reduce the weight of the vehicle by 12%, while ensuring that the structure does not deform during long-term use through high rigidity.
• 100g high weight specification: focusing on "high-strength load-bearing", suitable for core structural components of aerospace and industrial equipment, such as aircraft tail fins and high-pressure pipelines. The aircraft tail made of it can withstand extreme airflow impacts and maintain stable performance even in high-altitude and low-temperature environments of -50 ℃; When used for high-pressure pipelines, seamless molding is achieved through winding technology, with a pressure tolerance of over 48MPa, meeting the high-pressure transportation needs in the chemical and energy fields.

All specifications support customization of widths ranging from 0.9 meters to 1.3 meters, reducing the number of splices required in the production of large components and lowering process costs and quality risks at splices.

3. Comprehensive performance advantages to cope with complex service environments

In addition to core mechanical properties, UIN-36T unidirectional carbon fiber prepreg also has multidimensional performance advantages, which can adapt to complex usage scenarios in different fields:
Vibration attenuation and wear resistance: The product has excellent vibration attenuation performance, which can effectively absorb vibration energy, reduce noise and component wear in components that are prone to vibration such as automotive chassis and industrial machine tools; The friction coefficient is only 0.16 (about 0.5 for ordinary metals), and the wear resistance is 22% higher than that of ordinary carbon fiber prepreg. It is suitable for frequent friction scenarios such as mechanical joints and transmission components, extending the service life.

• Corrosion resistance and long service life: The resin system adopts acid and alkali resistant modified formula, and its service life can reach more than 14 years in corrosive environments such as marine ships and chemical equipment, which is 45% longer than ordinary carbon fiber prepreg. For example, when used for ship deck support structures, it can resist seawater salt spray erosion, avoid structural failure caused by material aging, and reduce maintenance frequency and costs.
• High plasticity and ease of processing: The product can be made into any shaped part according to the mold shape, whether it is the complex curved surface of the aircraft cabin wall or the streamlined structure of the sports car chassis, it can tightly fit the mold, and the dimensional accuracy error after molding is controlled within ± 0.2mm. During the processing, fibers are less prone to fuzzing and delamination, with a waste rate of less than 6%, far below the industry average of 10%, significantly reducing production costs.

4. Customization of resin system, expanding the application boundaries of scenarios

Different from traditional pre impregnated materials with fixed formulas, UIN-36T unidirectional carbon fiber pre impregnated materials support resin system adjustment as needed, and can optimize performance according to the special needs of different fields, further expanding application boundaries:

• In the aerospace field, high-temperature resistant resin is used to maintain stable performance of the prepreg in high temperature environments above 140 ℃, which is suitable for the use of aircraft engine peripheral components and spacecraft cabin structures.
• In the automotive industry, fast curing resins are used to shorten the curing time to less than 28 minutes, improve the mass production efficiency of sports car body parts, and meet the fast-paced production needs of the automotive manufacturing industry.
• In the fields of ocean and chemical engineering, corrosion-resistant resins are used to enhance the material's resistance to seawater and chemical reagents. For example, when used in high-pressure chemical pipelines, it can avoid the erosion of materials by acidic and alkaline media, ensuring transportation safety.
• In the field of high-end cultural and sports supplies, high toughness resins are used to enhance the impact and bending resistance of products. For example, golf club shafts can be buffered by resin toughness in the event of accidental impact, avoiding breakage and improving product durability.

5. Differentiated design, building market competition barriers

• Technological differentiation: The independently developed carbon fiber surface treatment process increases the bonding strength between carbon fiber and resin by 38%, solving the interface peeling problem that is prone to occur in traditional prepreg; The selection of fibers with a modulus of 36GPa not only meets the requirements of medium to high strength scenarios, but also has lower costs and significant cost-effectiveness advantages compared to high modulus products above 40T.
• Service differentiation: In addition to customized specifications and resins, we also provide supporting process support, such as providing optimization solutions for hot press molding parameters for aerospace customers, and providing molding process guidance for automotive customers, helping customers quickly solve technical problems in production and reduce landing barriers.
• Cost differentiation: Through large-scale production and process optimization, the cost of commonly used specifications such as 25g and 30g is controlled below the industry average by 12%, providing customers with a choice of "high performance+high cost-effectiveness", especially in cost sensitive fields such as high-end cultural and sports products and car modification, which is more competitive in the market.
